UNIQO 160

Fully automated IFA system – from primary sample to result proposal

The UNIQO 160 provides full IFA automation of the next generation – from the primary sample to the result proposal. This all-in-one solution maximises the efficiency of the entire IFA process, encompassing sample preparation, incubation, washing and mounting of slides as well as image acquisition. Via the interface to the EUROLabOffice 4.0 middleware, the indirect immunofluorescence with the UNIQO 160 can integrate seamlessly into the efficient workflows of diagnostic laboratories.

Up to 160 primary samples and 18 slides can be processed in one run on the compact benchtop instrument. During loading, samples, reagents and slides are automatically identified and assigned by their barcodes. As the slides are protected from drying out by automated mounting after incubation, brilliant fluorescence images are produced from the first to the last sample, even with large worklists. The integrated high-quality microscope with automatically changing objectives (4x, 10x, 20x) ensures optimal recording parameters for each product. This results in brilliant fluorescence images, which can be easily evaluated in EUROLabOffice 4.0. This is supported by the EUROPattern Classifier, which is compatible to EUROLabOffice 4.0, by automatically generating a result proposal, including the titer level.

  • Fully automated processing system from primary sample to result proposal for up to 160 samples and 18 slides
  • Flexible loading as well as complete traceability of samples, reagents and slides through automated barcode registration
  • Brilliant fluorescence images due to automatically mounted slides and the integrated high-quality microscope unit with automatically changing objectives (4x, 10x, 20x)
  • Computer-aided IFA evaluation based on deep convolutional neural networks using the EUROPattern Classifier

  • Features

    • Simple and secure result generation for up to 160 IIFT samples, 288 dilutions and 18 slides per run
    • Reliable assignment of samples, reagents and slides due to integrated barcode scanners
    • Flexible loading with up to 20 controls, 4 dilution buffers and 9 bottles of conjugate as well as mounting medium
    • Efficient pipetting of samples and reagents as well as washing of slides with the integrated three-needle system
    • High-quality recording of fluorescence images by means of autofocus and three automatically changing objectives (4x, 10x, 20x)
    • Data analysis and evaluation of the fluorescence images in EUROLabOffice 4.0

  • Specifications

    Operationfull HD touch-screen monitor, 15 inches
    Communication with LISvia EUROLabOffice 4.0, bidirectional
    Electrical data100 V – 240 V AC
    Dimensions / Weight1200 mm x 900 mm x 700 mm (W × D × H, without accessories) / approx. 150 kg
